Key Features and Benefits
- Self-developed Rotor: Independently developed high-precision rotor profiles ensure efficient and stable compressed air output.
- PTFE Coating: Rotor surfaces are coated with aerospace-grade PTFE for superior wear and heat resistance, extending service life by up to 30%.
- FAG Bearings: Equipped with premium German FAG bearings across the entire range, supporting 24/7 continuous heavy-duty operation.
- 100% Oil-Free: Advanced twin-screw differential pressure control technology keeps air pressure consistently higher than the oil side or creates a directional isolation airflow, ensuring 100% oil-free compressed air. Certified to ISO 8573-1 Class 0, it effectively prevents secondary contamination of bulk powder materials and ensures food-grade transport safety.
- Flexible Speed & Rotation Options: Supports both clockwise and counterclockwise rotation, with 1000 rpm and 1500 rpm speed options for flexible airflow and pressure matching under different unloading conditions.
- Wide System Compatibility: Compact and highly adaptable structure allows easy integration into truck-mounted air compressors, portable air compressors, PTO-driven air compressors, and stationary air compressors for diverse unloading and conveying applications.
Parameters
| Model | DEBOS-AIR-END |
| Profile | Asymmetric Profile |
| Type | Screw |
| Coating | Teflon |
| Rotation | Clockwise/Counter-clockwise |
| Volume | 487mm468mm417mm |
| Weight | 127kg |
| Service life | 8-10 years |
