Design Features
DEUTZ-Technology Diesel Engine: Equipped with a diesel engine based on DEUTZ technology, ensuring a stable and continuous compressed air supply.
Adapts to High Back Pressure: Capable of stable and rapid discharge of dry bulk materials even under high back pressure, ensuring high discharge efficiency.
100% Oil-Free Air: Delivers 100% oil-free compressed air, preventing material contamination and making it suitable not only for construction but also for food and chemical industries.
All-Weather Adaptability: Strong diesel power enables reliable operation in high-temperature, low-temperature, high-dust, and continuous heavy-duty environments.
Parameters
| Model | DEBOS Diesel Silobas Compressor |
| Driven Method | Diesel Driven |
| Airflow | 12m³/min; 450cfm |
| Pressure | 2.0bar |
| Input Speed | 1500rpm |
| Exhaust Temperature | 180-220℃ |
| Dimensions | 1930 x 716 x 1209mm (±3%) |
| Gross Weight | 527kg |
| Engine Model | Deutz Technoloy Diesel Engine |
| Engine Continuous Power | 41kw |
| Engine Max Power | 45kw |
| Engine Rotation | Clockwise (as clock hands) |
| Engine Displacement | 3.77L |
| Engine Bore x Stroke | 100 × 120mm |
